Microscope Cameras

Product Details:

Sony 48MP 4K HD-MI USB-C Sony Auto Focus Zoom Industrial Camera Monocular Microscope Zoom 180X



Application:

Lab, Mobile, PCB Boawithrd & Visual Inspection, Textile, Maintenance, Etc.

Lens Specification

Lens Zoom: 180X

Work Distance: 50 ~ 150mm

Camera Lens: C-Mount

Magnification Power: 0.7 – 4.5X

Visual Field: 2.8 X 1.5mm

Lens Size: 168 X 50mm

Camera  Specification

Camera: Ultra HD 4K Camera



Camera  Specification

Ø  Full HDMI 1080P@60FPS

Ø  Sony High sensitivity CMOS sensor

Ø  The camera uses HDMI cable to connect to the HD monitor. The dual USB ports of the camera can be connected to a mouse and USB stick to achieve the image capture or recording, no need to connect to computer。

Ø  The Type-C connector of the camera can connect to computer, which can achieve HDMI and USB 1080P@60fps sync output.

Ø  The camera can start within 5-second. With user-friendly WINDOWS style UI interface, so that  it's easy to operate even it's first time to use it

HDMI Specification

Output Resolution: 1920*1080

Frame Rate: (HDMI+USB) 60FPS

Image Storage: USB stick or computer

Video: 1920*1080@30FPS

Exposure Time: 0-999MS

Exposure: Auto and manual, providing target brightness settings

White Balance: Auto, manual and ROI mode

Parameter Setting: Contrast, saturation, gamma, sharpness, noise reduction etc

System Software: Youngwin OS

PC software: S-EYE2.0

Working Temperature: 0-60℃

Storage Temperature: -20-85℃

Size: 72*60*89.92mm

Power:   DC 5-12V

Product Details:

Sony Auto Focus Zoom Industrial Camera 150X 48MP 4K

HD-MI USB-C



Camera  Specification

Ø  Full HDMI 1080P@60FPS

Ø  Sony High sensitivity CMOS sensor

Ø  The camera uses HDMI cable to connect to the HD monitor. The dual USB ports of the camera can be connected to a mouse and USB stick to achieve the image capture or recording, no need to connect to computer。

Ø  The Type-C connector of the camera can connect to computer, which can achieve HDMI and USB 1080P@60fps sync output.

Ø  The camera can start within 5-second. With user-friendly WINDOWS style UI interface, so that  it's easy to operate even it's first time to use it

HDMI Specification

Output Resolution: 1920*1080

Frame Rate: (HDMI+USB) 60FPS

Image Storage: USB stick or computer

Video: 1920*1080@30FPS

Exposure Time: 0-999MS

Exposure: Auto and manual, providing target brightness settings

White Balance: Auto, manual and ROI mode

Parameter Setting: Contrast, saturation, gamma, sharpness, noise reduction etc

System Software: Youngwin OS

PC software: S-EYE2.0

Working Temperature: 0-60℃

Storage Temperature: -20-85℃

Size: 72*60*89.92mm

Power:   DC 5-12V

Product Details:

Sony CMOS Microscope Camera

Sony 48MP 4K HD-MI USB-C Industrial Camera

Digital Video Monocular Microscope Camera USB

 Zoom 150X



Camera  Specification:

Ø  Ultra HD 4K Camera

Ø  Using Sony Sensor

Ø  Using a 1/2.8-inch image sensor, the viewing angle is wider than that of 1/3-inch;

Ø  HDMI 1080P 60 frames image output;

Ø  TYPE-C driver-free output 1080P 30 frames image output;

Ø  4K video recording;

Ø  48 million photos, JPG format;

Ø  One-click freeze/thaw function;

Ø  1080P video recording;

Ø  Electronic zoom function;

Ø  Supports manual/automatic exposure/one-click exposure, exposure compensation value adjustment;

Ø  Supports manual/automatic white balance/one-click white balance, red, green and blue are adjustable;

Ø  Provides 16 line functions, with adjustable line color, thickness and position;

Ø  Provide center crosshair display/off;

Ø  Support TF card storage, up to 64GB;

Ø  Support remote control operation, take pictures without shaking and the image will be clearer;

Ø  Support Chinese, Traditional Chinese, and English menu languages;



Ø  Supports saving shutdown setting parameters;

Product Details:

Sony CMOS Digital microscope camera

SONY 10 INCH DISPLAY DIGITAL MICROSCOPE 1600X

with HDMI/USB output Extra Led Lights and Batteries





Specifications

Video Maximum Pixel: 1080P

Screen: 10.1-inch IPS LCD display with 1024*600 resolution

Lens Optic Size:  1/2.8"

Photo Resolution: 2M,3M,5M,8M,10M,12M,16M,20M, 24M, 48M

Video Resolution: 720P, 1080P

Video Format: MP4

Focus Mode: Manual

Picture Format: JPG

Illuminant: 8 LED lights (brightness adjustable)

PC Operating System: Windows 7, Windows 8.1, Windows10, Mac OS x 12 or higher

Interface and Signal Transmission Mode: Micro/USB 2.0/ Mini HDMI

Operating Temperature: -10°C~+55°C

Operating Humidity: 30%-85%RH

Working Current: 700mA

Power Dissipation: 3.5W

Language: English, French, Spanish, Portuguese, German, Italian, Simplified Chinese, Traditional Chinese, Russian, Japanese, Korean





Work with TV

Operating steps

Step 1. Connect LP101 to the TV via a HDMI cable

Step 2. After successful HDMI connection, the microscope will be turned on and the image will appear on the display. At this time, microscope button and remote-control button can be operated; when operating photo/video, the file will be automatically saved in TF card.

Photo mode

When the icon in the upper left corner of the microscope is Photo mode when the microscope is on, short press the Menu button on the microscope or short press the Photo button on the remote control, it can switch to Photo mode.

Video mode

When the icon on the upper left corner of the microscope is "it is in Video mode, when the microscope is on, short press the Menu button on the microscope or short press the Video button on the remote control, it can switch to Video mode

Work with PC

Software download - Download the applicable software

Packing List



Microscope, Bracket, Base, Type-C cable, Mini HDMI Cable, USB Cable, Straightdge, User Manual, Wireless Remote Control,

Product Details:

Monocular Microscope Camera

Sony 48MP 4K HD-MI USB-C Industrial Camera Digital Video Monocular Microscope Camera USB Zoom 180X







Application: Lab, Mobile, PCB Board & Visual Inspection, Textile, Maintenance, Etc.

Lens Specification

Lens Zoom: 180X

Work Distance: 50 ~ 150mm

Camera Lens: C-Mount

Magnification Power: 0.7 – 4.5X

Visual Field: 2.8 X 1.5mm

Lens Size: 168 X 50mm

Camera  Specification

Camera: Ultra HD 4K Camera

Sensor: Using Sony CMOS Sensor

Using a 1/2.8-inch image sensor, the viewing angle is wider than that of 1/3-inch

Output:  HDMI 1080P 60FPS, TYPE-C driver-free output 1080P 30FPS

Video: 4K video recording, 1080P video recording,

Photo: 48 million photos, JPG format, One-click freeze/thaw function

Camera Zoom: Electronic zoom function

Storage: Support TF card storage, up to 16 GB

Supports manual/automatic exposure/one-click exposure, exposure compensation value adjustment, Supports manual/automatic white balance/one-click white balance, red, green and blue are adjustable. Provides 16 line functions, with adjustable line color, thickness and position. Provide center crosshair display/off. Support remote control operation, take pictures without shaking and the image will be clearer. Support  English and Chinese menu languages. Supports saving shutdown setting parameters;

Product Details:

Sony 48MP 4K HD-MI USB-C Industrial Camera Digital Video Monocular Microscope Camera USB Zoom 180X



Application: Lab, Mobile, PCB Board & Visual Inspection, Textile, Maintenance, Etc.

Lens Specification

Lens Zoom: 180X

Work Distance: 50 ~ 150mm

Camera Lens: C-Mount

Magnification Power: 0.7 – 4.5X

Visual Field: 2.8 X 1.5mm

Lens Size: 168 X 50mm

Camera  Specification

Camera: Ultra HD 4K Camera

Sensor: Using Sony CMOS Sensor

Using a 1/2.8-inch image sensor, the viewing angle is wider than that of 1/3-inch

Output:  HDMI 1080P 60FPS, TYPE-C driver-free output 1080P 30FPS

Video: 4K video recording, 1080P video recording,

Photo: 48 million photos, JPG format, One-click freeze/thaw function

Camera Zoom: Electronic zoom function

Storage: Support TF card storage, up to 16 GB

Supports manual/automatic exposure/one-click exposure, exposure compensation value adjustment, Supports manual/automatic white balance/one-click white balance, red, green and blue are adjustable. Provides 16 line functions, with adjustable line color, thickness and position. Provide center crosshair display/off. Support remote control operation, take pictures without shaking and the image will be clearer. Support  English and Chinese menu languages. Supports saving shutdown setting parameters;

Product Details:

Monocular Auto Focus Microscope Camera

Sony Auto Focus Zoom Industrial Camera 180X 48MP 4K
MONOCULAR microscope 0.7-4.5x

HD-MI USB-C



Camera  Specification

Ø  Full HDMI 1080P@60FPS

Ø  Sony High sensitivity CMOS sensor

Ø  The camera uses HDMI cable to connect to the HD monitor. The dual USB ports of the camera can be connected to a mouse and USB stick to achieve the image capture or recording, no need to connect to computer。

Ø  The Type-C connector of the camera can connect to computer, which can achieve HDMI and USB 1080P@60fps sync output.

Ø  The camera can start within 5-second. With user-friendly WINDOWS style UI interface, so that  it's easy to operate even it's first time to use it

HDMI Specification

Output Resolution: 1920*1080

Frame Rate: (HDMI+USB) 60FPS

Image Storage: USB stick or computer

Video: 1920*1080@30FPS

Exposure Time: 0-999MS

Exposure: Auto and manual, providing target brightness settings

White Balance: Auto, manual and ROI mode

Parameter Setting: Contrast, saturation, gamma, sharpness, noise reduction etc

System Software: Youngwin OS

PC software: S-EYE2.0

Working Temperature: 0-60℃

Storage Temperature: -20-85℃

Size: 72*60*89.92mm



Power:   DC 5-12V

Product Details:

PCB Microscope Camera

Sony 48MP 4K HD-MI USB-C Industrial Camera Digital Video Monocular Microscope Camera USB Zoom 180X



Application: Lab, Mobile, PCB Board & Visual Inspection, Textile, Maintenance, Etc.

Lens Specification

Lens Zoom: 180X

Work Distance: 50 ~ 150mm

Camera Lens: C-Mount

Magnification Power: 0.7 – 4.5X

Visual Field: 2.8 X 1.5mm

Lens Size: 168 X 50mm

Camera  Specification

Camera: Ultra HD 4K Camera

Sensor: Using Sony CMOS Sensor

Using a 1/2.8-inch image sensor, the viewing angle is wider than that of 1/3-inch

Output:  HDMI 1080P 60FPS, TYPE-C driver-free output 1080P 30FPS

Video: 4K video recording, 1080P video recording,

Photo: 48 million photos, JPG format, One-click freeze/thaw function

Camera Zoom: Electronic zoom function

Storage: Support TF card storage, up to 16 GB



Supports manual/automatic exposure/one-click exposure, exposure compensation value adjustment, Supports manual/automatic white balance/one-click white balance, red, green and blue are adjustable. Provides 16 line functions, with adjustable line color, thickness and position. Provide center crosshair display/off. Support remote control operation, take pictures without shaking and the image will be clearer. Support  English and Chinese menu languages. Supports saving shutdown setting parameters;

Product Details:

Sony 48MP 4K HD-MI USB-C Industrial Camera Digital Video Monocular Microscope Camera USB Zoom 180X







Application: Lab, Mobile, PCB Board & Visual Inspection, Textile, Maintenance, Etc.

Lens Specification

Lens Zoom: 180X

Work Distance: 50 ~ 150mm

Camera Lens: C-Mount

Magnification Power: 0.7 – 4.5X

Visual Field: 2.8 X 1.5mm

Lens Size: 168 X 50mm

Camera  Specification

Camera: Ultra HD 4K Camera

Sensor: Using Sony CMOS Sensor

Using a 1/2.8-inch image sensor, the viewing angle is wider than that of 1/3-inch

Output:  HDMI 1080P 60FPS, TYPE-C driver-free output 1080P 30FPS

Video: 4K video recording, 1080P video recording,

Photo: 48 million photos, JPG format, One-click freeze/thaw function

Camera Zoom: Electronic zoom function

Storage: Support TF card storage, up to 16 GB

Supports manual/automatic exposure/one-click exposure, exposure compensation value adjustment, Supports manual/automatic white balance/one-click white balance, red, green and blue are adjustable. Provides 16 line functions, with adjustable line color, thickness and position. Provide center crosshair display/off. Support remote control operation, take pictures without shaking and the image will be clearer. Support  English and Chinese menu languages. Supports saving shutdown setting parameters;

Product Details:

PCB Inspection Repairing Microscope Camera

Pcb Inspection – Mobile Repair Handheld Microscope Camera Industrial 7 Inch Lcd Digital DIGITAL MICROSCOPE 1200 X WITH EXTRA LED LIGHTS AND LITHIUM BATTERIES



Parameter:

1: Pixel: HD 12 million pixels

2: Display: 7-inch high-definition LCD display.

3: Magnification: 1-1200 times continuous amplification system.

4: object distance: 10MM to infinity (different object distances correspond to different multiples)

5: Plug in the power supply or built-in super lithium battery. (Please pay attention to the built-in battery non-standard configuration)

6: Sixteen language systems: English, Spanish, Russian, Korean, Japanese, Thai, Hebrew, Portuguese, German, French, Italian, Turkish, Czech, Polish, Traditional Chinese, Simplified Chinese.

7: Power DC interface (Micro USB).

8: Flash card socket (MicroSD), supports 1-128GB. Class10 speed

9: Light level adjuster.

10: REST button, system restore button. (If the machine does not work, use a needle-like sharp object to press the button in the hole to restart the machine)

11: Highlight 8 LED lights, with a continuous service life of up to 100,000 hours.

In video mode:

Resolution: 1080FHD, 720P, VGA

Loop recording: Off / 3 minutes / 5 minutes / 10 minutes, after the flash card is full, the video data of the front will be deleted, and then the video will be saved.

HDR High Dynamic Range: On/Off (Automatically turn on the recording function if there is an object moving under the lens when it is turned on, no manual operation is required.)

Exposure compensation: 7-speed option

Date label: can select screen display / close - date time

In the photo mode:

Photo delay: single shot · 2 seconds · 5 seconds · 10 seconds

Photo pixel: 1.3M·2M·5M·8M·10M·12M

Continuous shooting: 3 continuous shooting

Photo quality: quality, standard, compression

Sharpness: strong · standard · soft

Color: None · Black and White · Nostalgia

ISO: Auto·100·200·400

Exposure compensation: 7-speed selection

Photo-assisted: anti-hand shake/off

Date Label: On/Off



Storage:

Watch: Up and down delete protection

D button: mode button:

Switch: camera mode, camera mode, playback mode:

Up button, down button, OK button (photo/video, open button)

Microscope



Digital 1600X Profocal Electron Microscope

* Industrial grade profocal lens * Touch control

* 12 millions HD pixels

* 2.4G wireless remote control

* LED shadowless lamp

* Support photography and video

* 1600x magnification

* Maintenance workbench

* 7inch IPS screen

* 3000mAh battery

* Support 128G memory card



Drawtube : Monocular

Light : LED shadowless lamp

Viewing screen : 7 inch IPS HD display

Pixel : 1200P

Magnification : 1600X

Knob focus range : 10MM-50MM

Support System : Windows XP, Vista, Win7/8/10/11, Mac11.0 or above

Video format : AVI

Material : ABS, multi-coated optical glass lens

Application : Electronic component amplification



Function Mobile repair, Biological research, Jewelry inspection

Product Details:

Mobile Repairing and PCB Inspection Microscope

Manual

Sony 48MP 4K HD-MI USB-C Industrial Camera Digital Video Monocular Microscope Camera USB Zoom 180X



Application: Lab, Mobile, PCB Board & Visual Inspection, Textile, Maintenance, Etc.

Lens Specification

Lens Zoom: 180X

Work Distance: 50 ~ 150mm

Camera Lens: C-Mount

Magnification Power: 0.7 – 4.5X

Visual Field: 2.8 X 1.5mm

Lens Size: 168 X 50mm

Camera  Specification

Camera: Ultra HD 4K Camera

Sensor: Using Sony CMOS Sensor

Using a 1/2.8-inch image sensor, the viewing angle is wider than that of 1/3-inch

Output:  HDMI 1080P 60FPS, TYPE-C driver-free output 1080P 30FPS

Video: 4K video recording, 1080P video recording,

Photo: 48 million photos, JPG format, One-click freeze/thaw function

Camera Zoom: Electronic zoom function

Storage: Support TF card storage, up to 16 GB

Supports manual/automatic exposure/one-click exposure, exposure compensation value adjustment, Supports manual/automatic white balance/one-click white balance, red, green and blue are adjustable. Provides 16 line functions, with adjustable line color, thickness and position. Provide center crosshair display/off. Support remote control operation, take pictures without shaking and the image will be clearer. Support  English and Chinese menu languages. Supports saving shutdown setting parameters;

Product Details:

Trinocular Biological Digital Microscope with 9" HD Display | Lab, Education | Camera-Compatible & Adjustable LED



Technical parameter

1、Eyepiece ：10X， wide-angle eyepiece
2、Objective ：4X、10X、40X（S）、100X(S、O)
3、Changer： 4-well-tilt converter

4、Eyepiece tube： Trinocular

5、Viewing head : tilted at 30 °, can rotate 360 ° 6、The refractive regulation ：±5
7、Objective table With spiral movement ruler, X-Y direction movement range: 60X40mm
size：110*120mm
8、The focus mechanism： Thick fine tuning coaxial，Fine-tune the lattice value：2μm
9、Condenser：Abbe concentrator NA. 1.25, up and down
10、Lamp source ：High-brightness, adjustable LED light
11、Collecting mirror： N.A.1. 25 The Abbe condenser lens 9-inch display screen parameters 1、Screen specifications ：9”
2、Display mode ：16:9/4:3
3、Screen resolution ：800X480
4、Visual range ：158X90mm
5、Applicable power supply ：DC-12V / 47-63 HZ / current 1.25A

Product Details:

Sony 48MP 4K HD-MI USB-C Sony Auto Focus Zoom Industrial Camera Monocular Microscope Zoom 180X



Application:

Lab, Mobile, PCB Boawithrd & Visual Inspection, Textile, Maintenance, Etc.

Lens Specification

Lens Zoom: 180X

Work Distance: 50 ~ 150mm

Camera Lens: C-Mount

Magnification Power: 0.7 – 4.5X

Visual Field: 2.8 X 1.5mm

Lens Size: 168 X 50mm

Camera  Specification

Camera: Ultra HD 4K Camera



Camera  Specification

Ø  Full HDMI 1080P@60FPS

Ø  Sony High sensitivity CMOS sensor

Ø  The camera uses HDMI cable to connect to the HD monitor. The dual USB ports of the camera can be connected to a mouse and USB stick to achieve the image capture or recording, no need to connect to computer。

Ø  The Type-C connector of the camera can connect to computer, which can achieve HDMI and USB 1080P@60fps sync output.

Ø  The camera can start within 5-second. With user-friendly WINDOWS style UI interface, so that  it's easy to operate even it's first time to use it

HDMI Specification

Output Resolution: 1920*1080

Frame Rate: (HDMI+USB) 60FPS

Image Storage: USB stick or computer

Video: 1920*1080@30FPS

Exposure Time: 0-999MS

Exposure: Auto and manual, providing target brightness settings

White Balance: Auto, manual and ROI mode

Parameter Setting: Contrast, saturation, gamma, sharpness, noise reduction etc

System Software: Youngwin OS

PC software: S-EYE2.0

Working Temperature: 0-60℃

Storage Temperature: -20-85℃

Size: 72*60*89.92mm

Power:   DC 5-12V
